Whirlpool® Top Load Electric Dryer with Steam-Enhanced Cycles - 7.0 cu. ft. YMED5430PBK
Whirlpool® Top Load Electric Dryer with Steam-Enhanced Cycles - 7.0 cu. ft. YMED5430PBK
Whirlpool
Whirlpool® Top Load Electric Dryer with Steam-Enhanced Cycles - 7.0 cu. ft. YMED5430PBK
Extra PowerExtra Power boosts drying power to get thick fabrics drier the first time.* *Results may vary based on load size and type.
Steam-Enhanced DryerSteam-enhanced dryers harness the power of steam to help prevent wrinkles and refresh clothes—even on deserted loads.
Advanced Moisture SensingAdvanced Moisture Sensing uses sensor strips to monitor moisture levels and temperatures, helping to get your largest loads evenly dried every time.
Wrinkle Prevent OptionDon’t worry about forgetting to take laundry out of the dryer. The Wrinkle Prevent option tumbles clothes for up to 150 minutes after the cycle ends to help prevent wrinkles from forming.
Quick Dry CycleDry a small load fast with the Quick Dry cycle, which pairs nicely with the Quick Wash cycle on select Maytag® washers to get clothes ready in no time.
7.0 cu. ft. capacityDry large loads with a spacious 7.0 cu. ft. capacity.
End of cycle signalAvoid forgotten laundry with the end of cycle signal so finished loads aren't left behind.
Steam Refresh CycleThe Steam Refresh cycle uses a fine mist in the heated dryer drum to relax wrinkles and revive clothes without washing.
Reduce Static OptionThe Reduce Static option cuts down on cling with the addition of a fine mist of water as clothes tumble at the end of the cycle.
Controls
Control LocationRear Console
End Of Cycle SignalYes
Control TypeKnob & Buttons
Feedback Status IndicatorsCool; Damp; Done; Sensing; Wet; Wrinkle Prevent
Electrical
Hz60
Volts240
Amps30
Configuration and Overview
Fuel TypeElectric
Compatibility
Works With
Cycles and Options
Cycle Time RemainingNo
Temperature Settings
Number Of Temperatures4
Installation Considerations
Long VentNo
Maximum Vent Length Ft64
Specifications
Country Of OriginUSA
Top Load MatchingYes
Front Load MatchingNo
Required AccessoriesW10044609A, W10623830
Product To Product Pairs
Extended Service Plan ParentEW04IW1Y, EW04IW2Y, EW04IW4Y
Features
Sound PackageNo
Automatic Dry ControlYes
Moisture SensorYes
Pedestal OptionsN/A
StackableNo
Lint Filter IndicatorNo
Certifications
ULYes
Energy Star QualifiedNo
Exterior
Door StyleSide Swing
Reversible DoorYes
Details
Hoses IncludedNo
Drum MaterialPowder Coat
Quad BafflesYes
Lint Screen LocationTop
Cycles
Number Of Dryer Cycles10
Drying Cycles Selections45 min Dry; 60 min Dry; 90 min Dry; Air Only (90 min); Bulky Items; Casual; Delicates; Normal; Steam Refresh
Options
Number Of Dryer Options4
Dryer Option SelectionsExtra Power; Temperature; Wrinkle Prevent; Wrinkle Prevent w/Steam
Carton Depth29.0"
Carton Height45.0"
Carton Width31.0"
Gross Weight139.0 lbs.
Net Weight122 lbs.
Depth With Door Open 90 Degree51.0"
Depth28.25"
Height43.0"
Maximum Height43.0"
Minimum Height39.0"
Width29.0"
Capacity IEC CAN (cubic feet)7
